【Scope of application】

Special equipment for degassing test water for hydraulic tests related to geosynthetics, or connected to other geosynthetics equipment through hoses, can effectively remove the gases contained in the water, including oxygen, carbon dioxide, etc., and provide necessary testing Degassed water. It also provides the constant water temperature required for the experiment, which is used as a constant temperature source to provide a field source with controlled heating and cooling, uniform and constant temperature for the test work, and conduct constant temperature tests or tests on test samples or products produced.

【technical parameter】

1. Temperature range: 15～105℃

2. Temperature correction accuracy: ±0.1℃

3. Volume: 50L

4. *Large cooling capacity: 13000W

5. Circulation mode: inner circulation

6. Constant temperature method: cooling, heating, hot air bypass

7. Cooling method: air cooling

8. External circulation pump: 75W, adjustable flow

9. Display mode: LCD touch screen display

10. PID control: with PID self-tuning function

11. Safety protection: 8 types of multiple protection devices such as overheating, overcurrent, phase sequence, high pressure, low pressure, liquid level, over temperature, etc.

12. Heating time: 30min

13. Refrigeration time: 30min

14. Temperature accuracy: ±2℃

15. Compressor power: 3.0KW

16. Circulating pump power: 350W

17. Circulating pump flow rate: 45L/min

18. Power supply voltage: 380V/50HZ, 12KW

19. Maximum total power: 16KW

20. Size: 1200*600*900mm

21. Weight: 180KG
