【Scope of application】

Mainly used for the tensile strength test of new building waterproof materials (including new waterproof coiled materials, waterproof coatings, waterproof sealing materials, etc.), that is, under the set speed condition, the sample within the gauge length is stretched to measure The force at break can also be used to test the tensile properties of other non-metallic materials.

【Standards compliant】

GB/T 328.8 Test Method for Building Waterproof Coiled Material Tensile Performance of Bituminous Waterproof Coiled Material

GB/T 328.9 Test Method for Building Waterproof Coiled Material, Polymer Waterproof Coiled Material, Tensile Performance

GB/T 328.18 Test method for building waterproofing membrane, bituminous waterproofing membrane, tearing performance (nail rod method), etc.

【technical parameter】

1.Test method: Constant velocity elongation (CRE) test principle measurement, the whole process is controlled by a high-speed processor, and every hour is recorded Change every moment (curve dynamic monitoring), and breaking strength, breaking elongation (elongation), time, frequency, etc.

2.Test method: microcomputer control

3. Measuring range: 500N / 1000 N / 2500N / 5000N / 10000N (optional)

4. Force measuring accuracy: ≤±0.02%F.S

5. Adjustment accuracy of clamping distance: ±0.1mm

6. Stretching speed: 0.001-500mm/min digital speed regulation, error ≤±2% (arbitrarily set)

7. Gantry width: 420mm

8. Effective stroke: 1000mm

9. Elongation resolution: 0.001mm

9. Sampling frequency: 2500 times/sec

10. Holder: waterproof coiled material stretching fixture, nail bar tearing fixture (optional for large deformation extensometer)

11. Maximum cumulative test times (maximum data capacity of continuous test): 5000 times (can be grouped arbitrarily)

12. Print: output print results in various forms

13. Power supply: AC220V±10％50Hz

14. Dimensions: 820×650×1750mm (L×W×H)

15. Weight: about 180 Kg
