【Scope of application】

It is used to test the resistance of petroleum asphalt felt, polymer roofing waterproofing membrane and other waterproofing material products to standing water or the ability of limited surface to withstand water pressure. This method is used for low-pressure applications of membranes, such as roofing, base layer, and air barrier. Layers and so on.

【Standards compliant】

GB/T328.10-2007 Method A GB18242-2000, GB18243-2000

【technical parameter】

1. Display: LCD digital display

2. Test pressure range: 0-100Kpa

3. Accuracy: 1 Kpa

4. Inner diameter of permeable tray: Φ150mm

5. Glass plate: 5mm, water pressure ≤10 Kpa; 8mm, water pressure ≤60 Kpa;

6. Dimensions: 700×550×1650mm (W×D×H)

7. Power supply: AC220V, 100W

8. Weight: 130KG
