【Scope of application】

It is used to test the mechanical properties of various textiles such as stretching, tearing, bursting, constant elongation, constant load, elasticity, suture slip, and peeling.

【Related standards】

GB/T3923.1, ISO13934.1, ISO13935.1, ISO9073.3/4, ASTM D5035, ASTM D2261 GB 19083-2010, FZT 64078-2019

GB 2626-2006 etc.

YY 0469-2004 Technical requirements for medical surgical masks

YY/T 0969-2013 disposable medical masks

GB/T 32610-2016 Technical Specification for Daily Protective Masks

FZT 64078-2019 Meltblown nonwoven fabric

【technical parameter】

1. Structure: Single arm type (including computer interface)

2. Measuring force range: 3000N

3. Effective stroke: 1000mm (without fixture)

4. Load measurement range: 0-100% of the maximum load

5. Load measurement accuracy: +0.02% F·S

6. Beam displacement speed: 0—500mm/min stepless speed regulation

7. Speed accuracy: ±2%

8. Dimensions (mm): 500×400×1400

9. Fixture configuration: a set of tensile fixtures (other functional fixtures can be customized according to user test requirements)

10. Power supply: single-phase AC 220V±10%V

11. Weight: 90kg
