【Scope of application】

It is used to test the water vapor transmission rate of medical wound dressings and other related materials when they are exposed to water vapor under certain temperature and humidity conditions.

【Standards compliant】

YY-T 0471.2-2017 Test method of contact wound dressing part 2

【technical parameter】

1. Number of test tubes: 5

2. The inner diameter of the test tube: 35.7±0.1mm

3. Test cylinder capacity: 20mL

4. Opening area of ring splint: 10cm2

5. Temperature range: 5℃～100℃

6. Tolerance of temperature fluctuation: ±2℃

7. Tolerance of temperature uniformity: ±2℃

8.Relative humidity range: 10%RH～98%RH, the relative humidity can be kept below 20%RH when the temperature is 37±.1℃

9. Temperature fluctuation: ±2%RH

10. Wind speed: 0.3-1.5m/s

11. Weighing range: 0-200g, accuracy 0.0001g

12. Display mode: color touch screen

13. Observation window: transparent tempered glass with lighting function

14. Studio size: 500×600×400mm

15. Dimensions: 1050×1080×1750mm

16. Power supply: AC 220V 50/60HZ

17. Weight: 250KG
