【Scope of application】

This instrument is suitable for testing floor coatings, floor paint films, floor coverings, artificial leather, synthetic leather, etc. under certain pressure conditions to test the degree of friction resistance.

【working principle】

Prepare 6 samples with a size of 150mm*150mm. Under a certain pressure, the sample and the standard abrasive will rub against each other according to the movement track of the Lissajous curve, resulting in damage to the sample. The number of wear resistance of the sample is broken Indicates the abrasion resistance of the fabric.

【Standards compliant】

CEN/TS 16611

BS EN16094-2012 Laminated wood flooring. Test method for determination of micro-scratches

【technical parameter】

1. Number of workstations: 4

2. Counting range: 0～999999 times

3. Maximum stroke: Horizontal: 60±0.5mm Longitudinal: 24±0.5mm

4. The quality of pressurized material:

A.413±2g (nominally called 4N) Stainless steel material

B.612±2g (nominally called 6N) Stainless steel material

5. Test station diameter: 14cm diameter non-threaded press cap station

6. The relative speed of the gripper and the grinding table: 50±2r/min, 47±2r/min

7. Dimensions: 885×600×410mm

8. Electricity source: Ac220V 50Hz 500W

9. Weight: 150kg
