【product description】

Under laboratory conditions, evaluate the electrostatic characteristics of the fabric after being charged in the form of friction.

【Standards compliant】

FZ/T01060 GB12059 GB/T12703 etc.

【technical parameter】

1. Measuring range of electrostatic charge: 0-2цC, accuracy: ±0.001цC

2. The friction cloth is nylon or acrylic, size: 400mm×450mm

3. There are three samples in the warp and weft directions, and the size of the sample is 250mm×350mm

4. Operating conditions of the drum friction machine: Operating time: 15min Temperature inside the drum: 60±100C

5. Technical specifications of roller friction machine (Required by E law in GB/T12703-91)

specifications

The inner diameter of the drum ≥460mm The diameter of the drum ≥280mm

Drum depth ≥350mm Drum revolutions ≥45r/min

Number of drum blades 3 Drum lining material Nylon, polypropylene standard cloth

Heating method Electric temperature and wind method Exhaust volume ≥2m3/min

Others The entrance and exit of the sample are covered with double-sided tape、
