【Scope of Application】

It is used in the field of laboratory textile and clothing, rubber, plastic, leather, toys, paper testing and sample preparation, and can prepare samples required for testing of physical properties and chemical items.

【Related standards】

GB/T2912.1, GB/T4669, GB/4802, GB/T19976, GB/T3923, etc.

【technical parameter】

1. Display: 7.8 inch touch screen display, Chinese menu

2. Diameter of pressure plate: 20*20cm

3. Air pressure: 4kg/cm2

4. Working pressure: the working pressure is 10 tons, and the working air pressure is not less than 0.5MPa.

5. Sample size: According to different test requirements, samples of different sizes and sizes can be prepared with the knife mold, the sample size is 5*5mm

6. Sample preparation efficiency: a complete sample preparation process: about 20 seconds; sample preparation weight: depends on the sample material and die. When preparing 5mm*5mm textile samples, about 20g can be prepared at one time, and it can meet the needs of formaldehyde, PH value, banned azo, component quantification, pesticide residues and other test items.

7. Sample preparation mode: automatic, manual mode (optional)

8. Adjustable rotation angle: 30°—180°

9. Sample preparation mode: gas-liquid double-cylinder pressurization mode, uniform knife edge, safe and reliable

10. Electricity source: Ac220V 50Hz

11. Dimensions: 600*550*1350mm (L×W×H)

12. Weight: 180kg
