【Scope of application】

It is used to adjust the temperature and humidity of various textiles before testing the physical and mechanical properties.

【Related standards】

GB6529 ASTM D 1776, etc.

【technical parameter】

1. Temperature range: -20℃ -150℃

3. Humidity range: 20%— 98%RH

4. Temperature and humidity control accuracy: ±0.5℃; ±2.5%RH

5. Uniform temperature and humidity distribution: ±2.0℃; ±3.0% R.H

6. Heating time: from room temperature to 100°C, within 30 minutes (no load)

7. Cooling time: from room temperature to -40°C, within 65 minutes (no load)

8. Inner box material: SUS#3041.0mm mirror stainless steel plate

9. Outer box material: steel plate spray treatment or stainless steel sand grain treatment

10. Thermal insulation material: PV rigid foam + glass wool

11. Studio size: 400×500×400mm

12. Dimensions: 600×1045×1610mm

13. Power: 4000W 20A

14. Power supply: AC 220V 50/60HZ

15. Weight: 180KG
