Model

 JG6500

Temperature control of test chamber

 20～93℃； Resolution::0.1℃

Test chamber humidity control

 Bright cycle：10-75%RH，Humidity fluctuations±3%RH; Dark cycle ：10-95%RH，Humidity fluctuations±5%RH;

Test time control

 0min~999:59h，Precision±1min

Irradiance control

 0.8～2.5W/m2/420nm  Precision：±0.03W/m2/420nm；Digital setting, automatic compensation

Controllable and monitoring wavelength

 Optional340nm、420nm、300-400nm、300-800nm band

Xenon arc lamp rated power

 6.5KW

 Rotation speed of sample holder

 1-10rpmCan be set

Diameter of sample holder distribution

 φ650mm

Maximum exposure area

 6900cm2

Dimension and number of sample holders that can be installed

 145×75mmTemplate  68 piece;145×45mm Template 90Only

Each sample holder is timed separately

 ≤10000h

Illumination period

 ≤10000h

Spray cycle

 ≤10000h

Display control

 （BPT） 30-100℃±2℃;（BST） 35-105℃±2℃

Display control

 10.4-inch touch screen

Data output

 Digital color screen display (A4 Chinese and English printing option)

Sample rack type

 Three layers

External circulating water requirements

Tap water pressure:140-1345kPa        flow:1.5L/min

Internal circulating water requirements

 High purity water flow：0.8L/min

power supply

 AC380V±5% 50Hz  12kW

Dimensions

 1350×1050×1900mm

weight

 460kg
