Type No

YG611-IIItype

YG611-IVtype

YG611-Vtype  (high temperature)

Function mode

It has light, rain, light and dark alternation, revolution, and autobiography. The light and dark alternation function strictly follows the American standard test requirements. The xenon lamp is automatically turned on and extinguished at the specified time, and it is automatically adjusted according to temperature and humidity.

Temperature control range of test chamber

25～70℃； Resolution:0.1℃

25～70℃； Resolution:0.1℃

25～70℃； Resolution:0.1℃

Test chamber humidity control range

Light cycle:10～70％RH；Resolution:0.1%       Dark cycle: 30～95％RH；Resolution:0.1%

Standard blackboard thermometer

40～85℃  Accuracy:±1℃

40～85℃  Accuracy:±1℃

40～100℃  Accuracy:±1℃

Blackboard thermometer (optional)

40～80℃  Accuracy:±2℃

40～80℃  Accuracy:±2℃

40～95℃  Accuracy:±2℃

Test time control range

≤10000h

Irradiance control range

0.80～2.01W/m2@420nm；（Optional340nm、420nm、300-400nm and 300-800nmBand）
Accuracy:±0.02W/m2@420nm；Digital setting, closed loop automatic compensation

Xenon arc lamp rated power

2.5KW

3.0 KW

3.5 KW

Rotation speed of sample holder

Revolution  5r/min；rotation： 180°/Turn (customized)
