【Scope of application】

It is used to test the color fastness of cotton, chemical fiber, blended fabric and other colored fabrics and leather to dry and wet rubbing and scrubbing.

【Related standards】

ISO105X12, GB/T3920/5712/420, AATCC8/165, BS1006 D02

【Technical Index】

1. The size of the friction head: ⑴Φ16mm±0.1mm (round)

⑵19mm×25.4mm (square)

⑶ Arc R18

⑷Curved R45

2. Pressure of friction head:

⑴Φ16mm±0.1mm (round)+post+flat pad=335g

⑵19mm×25.4mm (square) + column=330g

⑶Curved R18+post=450g

⑷Arc R45+Column=340g

*The above weight is the actual weighing weight, the error is less than 1%.

3. Motor head stroke: 0～140mm

4. Reciprocating speed: 0～60 times/min

5. Setting range of reciprocating times: 1～9999

6. Power supply: AC 220V±10% 50HZ

7. Power of the whole machine: 25W

8. Volume: 605mm×400mm×260mm
