【Scope of application】

It is used to test various yarn twists, twist unevenness and twist shrinkage.

【Related standards】

GB/T2543.1/2 FZ/T10001 ISO2061 ASTM D1422 JIS L1095

【technical parameter】

1. LCD screen size: 60mm×110mm

2. Control mode: computer program control, data processing, print output results

3. Pre-tensioning method: horizontal pulley balance swing mechanism, horizontal hanging weight pre-tensioning

4. Output mode of test results:

a. Display search output

b. Printer printout

5 Test method

a Direct counting method b One-time untwisting and twisting method c Two-time untwisting and twisting method d Three-time untwisting and twisting method

6 Test length 25, 50, 100, 200, 500mm

7 Measuring range 1～9999.9

8 Test speed 500～2000r/min

9 Dimensions L1070×W240×H200mm
