【Scope of application】

It is used to test the bulkiness of down and feathers and product filling materials, meeting GB, DN and JIS test standards.

【Related standards】

GB/T14272-2011, GB/T10288-2003, IDFB-FP, FZ/T80001, JIS L 1903 BS EN 12130

【technical parameter】

1. Measuring accuracy: 0.1 mm;

2. Measuring height: 750 mm, in line with the new national standard;

3. Measuring speed: 0-1000 mm/min can be set;

4. Displacement distance of test tube: 0-620mm

5. The inner diameter of the measuring cylinder: 284 mm 240 mm

(Optional 290 mm JIS L 1903 BSEN12130 FZ/T80001)

6. Measuring platen: 94.25g diameter 284 mm; 68.4g diameter 240 mm

68.4g diameter 282 mm (optional FZ/T80001)

120 g diameter 285 mm (optional JISL 1903)

7. Air supply speed: 2～40L/S Adjustable

8. The rising and falling speed of the pressure plate: 1~1000mm/min can be set

9. The lowering speed of the press board: 1-1000mm/min can be set

10. Blowing time: 0:00-99:59 minutes: seconds can be set

11. Pressing time: 0:00-99:59 minutes: seconds can be set

12. Data output: parallel printing interface or USB interface

13. Power supply AC220V±10% 50Hz 1100W

14. Host size: 1100×380×1650 cm (W×L×H)
