【Scope of application】

It is suitable for testing mechanical properties such as breaking strength, breaking elongation and initial modulus of various engineering fibers. A tensile test can be performed on short fibers used in engineering to show test data such as breaking strength, breaking elongation, elongation load, strength, and modulus.

【Instrument characteristics】

●Intelligent and smart touch interface, 5.7-inch large screen can be clicked at will.

●The structure design of independent intellectual property rights can test up to 1000cN, which is suitable for different fibers such as metals and chemistry.

●Adopt advanced digital signal processing (DSP) technology, Philips 32-bit fully digital control and 2500 f/s high-speed data acquisition.

●Obtained the National Intellectual Property Office's Computer Power Testing Software Approval and Protection Certificate (Certificate No.: 2011SR003281).

【Related standards】

GB/T 21120-2018, GB/T9997-2008, GB/T14337, JT∕T 524-2019, ISO5079, ISO11566, etc.

【technical parameter】

1. Maximum load test: 100cN 300cN 500cN 1000cN

2. Load test error: 0.02% (F.S)

3. Load test sensitivity: 0.01cN

4. Maximum elongation measurement range: 650mm

5. Resolution of elongation measurement: 0.01mm

6. Zero drift: ≤0.2%(F.S)

7. Lower gripper descending speed: 1～200mm/min (digital setting)

8. Lowering speed error: ≤1%

9. The rising speed of the lower gripper: 200mm/min

10. Data output: equipped with special test software, can be operated online, and print out test reports

11. Power supply: AC220V±10%, 50Hz

12. Dimensions: 440×410×800mm (L×W×H)

13. Weight: about 70kg
